| Model | NAFS Rating | Test Size | Max SIZE | (PSF)Design Pressure | (CFM/FT2)Air Infiltration | (PSF)Water Resistance | Structural Overload | CR | U-Value | SHGC | OITC/STC | Visible Trans. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Picture | AW-PG100 | 72” x 120” | 144" x 144" | 100 | 0.01 | 12.11 | 120.3 | 49-68 | 0.15-0.29 | 0.24-0.36 | 28-35 / 28-44 | 0.30-0.67 |
| Awning | AW-PG70 | 48” x 72” | 72" x 84" | 70.18 | 0.01 | 12.11 | 105.26 | 51-65 | 0.20-0.32 | 0.19-0.29 | 28-35 / 28-44 | 0.25-0.53 |
| Casement | AW-PG70 | 48” x 84” | 48" x 96" | 70.18 | 0.01 | 12.11 | 105.26 | 51-66 | 0.20-0.32 | 0.19-0.29 | 28-35 / 28-44 | 0.15-0.53 |
| Corner Window | CW-70 | 120” x 120” | 144" x 144" | 70.18 | 0.01 | 12.11 | -- | -- | 0.24-0.29 | 0.24-0.29 | -- | -- |
| Multi-Slide Door | R-15 | 180" x 144" | 60" x 144" | 15 | 0.034 | 4.5 | -- | -- | 0.34-0.39 | 0.21 | -- | -- |
| Swinging Door | R-50/LC-50 | 72" x 83" | 48" x 144" | 45 | 0.06 | 4.59 | -- | -- | 0.27-0.31 | 0.19 | -- | -- |
| Sliding Door | R-50/LC-50 | 87" x 83" | 120" x 144" | 35 | 0.01 | 7.52 | -- | -- | 0.29-0.31 | 0.21 | -- | -- |
| Corner Door | -- | -- | 48" x 72" | -- | -- | -- | -- | -- | -- | -- | -- | -- |
| Lock Box Door | LC-PG50 | 48" x 120" | 48" x 120" | 90 | 0.09 | 7.52 | -- | -- | 0.39 | 0.22 | -- | -- |
| Model | NAFS Rating | Test Size | Max SIZE | (PSF)Design Pressure | (CFM/FT2)Air Infiltration | (PSF)Water Resistance | Structural Overload | CR | U-Value | SHGC | OITC/STC | Visible Trans. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Multi-Slide Door | R-15 | 180" x 144" | 60" x 144" | 15 | 0.034 | 4.5 | 0.38 | 0.21 | ||||
| Lock Box Door | LC-PG50 | 48" x 120" | 48" x 120" | 90 | 0.09 | 7.52 | -- | -- | 0.39 | 0.22 | -- | -- |
| Swinging Door (Inswing) | LC-PG50 | 48” x 96” | 48" x 120" | 90 | 0.09 | 7.52 | 50.13 | 45 | 0.39 | 0.22 | N/A | 0.40-0.49 |
| Sliding Door | AW-PG50-SD | 123” x 95” | 48" x 72" | 50 | < 0.01 | 12 | 75 | 42-45 | 0.34-0.39 | 0.21-0.48 | N/A | 0.47-0.58 |
| Single Hung | AW-PG50 | 60” x 99" | 72" x 132" | 51.12 | 0.10 | 10.66 | 90* (projected) | 45-48 | ≤ 0.30 | 0.21-0.32 | N/A | N/A |
| Casement | CW-80 | 36” x 60" | 48" x 84" | 80.2 | 0.012 | 12.11 | 105* (projected) | 45-48 | 0.39-0.43 | 0.21-0.32 | N/A | 0.27-0.56 |
| Awning | CW-80 | 60” x 36” | 72" x 84" | 80.2 | 0.12 | 12.11 | 105* (projected) | 40-49 | 0.21-0.32 | 0.21-0.32 | N/A | 0.27-0.56 |
| Picture | AW-110 | 72” x 120” | 144" x 144" | 100.3 | 0.01 | 15.04 | 165.4 | 49-62 | 0.26-0.31 | 0.24-0.37 | N/A | 0.20-0.68 |
| Model | NAFS Rating | Test Size | Max SIZE | (PSF)Design Pressure | (CFM/FT2)Air Infiltration | (PSF)Water Resistance | Structural Overload | CR | U-Value | SHGC | OITC/STC | Visible Trans. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Picture | AW-PG90 | 60" x 60" | 144" x 144" | 90.22 | 0.01 | 12.11 | N/A | 51-65 | 0.14-0.28 | 0.19-0.29 | 25-31 / 30-36 | 0.31-0.66 |
| Awning | AW-PG70 | 48" x 72" | 72" x 84" | 70.18 | 0.01 | 12.11 | 70.18 | 48-62 | 0.17-0.28 | 0.24-0.36 | 28-35 / 28-44 | 0.25-0.53 |
| Casement | AW-PG70 | 48" x 84" (Maximum) 36" x 72" STC/OITC | 48" x 96" | 70 | 0.01 | 12.11 | 70.18 | 51-64 | 0.17-0.28 | 0.19-0.29 | 22-33 / 27-37 | 0.25-0.53 |
| Swinging Door | R-50/LC-50 | 72x83 | 48" x 144" | 45 | 0.06 | 4.59 | -- | -- | 0.24-0.29 | 0.19 | -- | -- |
| Sliding Door | R-50/LC-50 | 87x83 | 168" x 144" | 35 | 0.01 | 7.52 | -- | -- | 0.26-0.31 | 0.21 | -- | -- |
