Picture Windows

The C600 window series’ provide the perfect combination of exceptional Performance and Flexibility. OptiCore windows are ideal for creating a unique architectural design with a mixture of fixed and awning units. The result is an abundance of natural daylight, full ventilation, maximum energy efficiency and a custom architectural style.
ARRASTRA PARA ROTAR
DRAG TO ROTATE

Features

Framing System

  • Patented OptiCore
  • Technology
  • Architectural grade aluminum frame
  • Dual Euro-Groove frame system

Enhanced Design

  • Azo-Core Thermal Barrier System for reduced thermal- conductivity and increased
    energy-efficiency
  • Modern, squared frame glazing
  • 2 7⁄8’’ narrow sitelines
  • With or without Integral Nailing Fin

Glazing

  • 1’’ insulating glass
  • Dual-sealed Warm Edge Super Spacer system

Hardware

  • Commercial-grade Amesbury/Truth lock and crank-out system Screen
    Easily removable
  • FlexScreen system carries a lifetime warranty

Benefits

  • Capacity to match exterior colors for unique project facades
  • Two-tone capabilities with a color to match the building interior and another to match the exterior
  • Maximum sizing affords the facilitation of large sizes for taller and wider window openings
  • Thermal performances never thought achievable in aluminum windows

options

Available Configurations

  • Project-out awning
  • Wire frame capabilities

Enhanced Design

  • Traditional/Historic beveled frame glazing (C605 Series)
  • Muntin Choices
  • Internal or simulated divided lites available

Hardware and Screen

  • ADAHardware
  • Limited travel hardware
  • Retractable screen systems

Glazing

  • Multiple Low-E and argon glazing choices
    Impact-rated glazing package
  • Glazing pocket can accept up to 13⁄8” insulating glass for
    sound attenuation purposes
  • Triple glazing
  • Capillary tubes
  • Wide variety of tinting and pane thickness options

Panning Trim Choices

  • Wide variety of panning, receptor and trim available

Mulling

  • Wide variety of structural mulls

PERFORMANCE

Model Awning (Project-Out) Awning (Project-Out)
NAFS Rating AW-PG100-AP AW-PG70-AP
Test Size 48” x 72” (max
Design Pressure (P.S.F.) 105.26
Air Infiltration at 25 MPG (cfm/ft2) .09* .09
Water Resistance (P.S.F.) .09* .09
CR (Condensation Resistance) 50-80
U-value (ranges based on multiple Low-E/Argon combinations) 0.19-0.30
SHGC (ranges based on multiple Low-E/Argon combinations) Awning (0.11-0.44)
OITC/STC Awning (28-35 / 28-44)

A color for every space.

Architectural Paint coatings and finishes meet AAMA 2604 (an FGIA specification) and are available in unlimited colors
